Titanium Carbide Powder (TiC)

Titanium Carbide Powder Price & List

Spec.	Purity	Shape	Available
TiC-UI300	≥99%	Irregular	APS 200-400 nm
TiC-UI500	≥99%	Irregular	APS 400-600 nm
TiC-FI001	≥99.5%	Irregular	F.S.S.S 1.0-1.5 um
TiC-FI002	≥99.5%	Irregular	F.S.S.S 1.5-2.0 um
TiC-FI003	≥99.5%	Irregular	F.S.S.S 2.0-3.0 um
TiC-FI005	≥99.5%	Irregular	F.S.S.S 4.5-5.5 um
TiC-FI012	≥99.5%	Irregular	F.S.S.S 10.0-13.0 um
TiC-DS015045	≥99.5%	Spherical	15-45 um
TiC-DS015053	≥99.5%	Spherical	15-53 um
TiC-DS045105	≥99.5%	Spherical	45-105 um
TiC-DS045150	≥99.5%	Spherical	45-150 um
Customizable	≥99%	Customizable	Sieve as required

Note: We provide customized service. If you don't find the powder you want, please send us an email directly. We can customize it according to your requirements.

Titanium Carbide Powder

Titanium carbide is a kind of carbide with gray black appearance. The chemical formula is TiC and the molecular weight is 59.89. The melting point is 3140 ± 90 ℃, boiling point 4820 ℃, relative density 4.93. Titanium carbide is insoluble in water, but soluble in nitric acid and aqua regia. According to different shapes, titanium carbide powder can be divided into irregular titanium carbide powder, spherical titanium carbide powder, and agglomerated spherical titanium carbide powder. According to the different particle sizes, titanium carbide powder can be further divided into coarse titanium carbide powder, fine titanium carbide powder, extremely fine titanium carbide powder, ultrafine titanium carbide powder, and nano titanium carbide powder.

Titanium Carbide Powder Application

Titanium carbide powder has the characteristics of high hardness, corrosion resistance, and good thermal stability, and can be used as an additive for cutting tool materials. It can also be used as a melting crucible for bismuth, zinc, and cadmium metals, to prepare semiconductor wear-resistant films, as well as for HDD large capacity memory devices, and as a metal ceramic. The details are as follows:

Irregular Titanium Carbide Powder

Irregular titanium carbide powder is mainly used to manufacture cermets, heat-resistant alloys, and hard alloys. Adding 6-30% TiC to the Wc Co based hard alloy to form a TiC-WC solid melt with WC can significantly improve the alloy's red heat resistance, wear resistance, oxidation resistance, corrosion resistance, and other properties, making it more suitable for processing steel than WC Co hard alloy. Tungsten free hard alloys can also be made using alloys such as Ni Mo as binders, which can improve turning speed, precision, and smoothness of machined parts. The details are as follows:
1. Used as additive of cutting tool material and melting crucible of Bi, Zn and Cd;
2. Used to prepare semiconductor wear-resistant film and HDD large capacity memory device;
3. Used as cermet;
4. Used as deoxidizer in steelmaking industry;
5. Used to make cutting tools.

Spec.	Purity	Shape	Available
TiC-FI001	≥99.5%	Irregular	F.S.S.S 1.0-1.5 um
TiC-FI002	≥99.5%	Irregular	F.S.S.S 1.5-2.0 um
TiC-FI003	≥99.5%	Irregular	F.S.S.S 2.0-3.0 um
TiC-FI005	≥99.5%	Irregular	F.S.S.S 4.5-5.5 um
TiC-FI012	≥99.5%	Irregular	F.S.S.S 10.0-13.0 um
Customizable	≥99%	Customizable	Sieve as required

Ultrafine Titanium Carbide Powder

Ultrafine titanium carbide powder refers to a submicron level titanium carbide powder with a particle size between 100-1000 nm. Compared with nanopowder, it has better economy. Compared to fine powder and extremely fine powder, it also has excellent performance. It is mainly used in fields such as cutting tools, coating materials, ceramic additives, etc.


Spec.	Purity	Shape	Available
TiC-UI300	≥99%	Irregular	APS 200-400 nm
TiC-UI500	≥99%	Irregular	APS 400-600 nm
Customizable	≥99%	Customizable	Sieve as required

Spherical Titanium Carbide Powder

Spherical titanium carbide powder is a type of spherical titanium carbide powder prepared by plasma spheroidization process using irregular titanium carbide powder raw materials. Compared to agglomerated titanium carbide powder, spherical titanium carbide powder has better flowability. It is commonly used in the following occasions and fields:
1. Used for 3D printing / additive manufacturing;
2. Used for laser cladding;
3. Used in plasma spraying and other applications.


Spec.	Purity	Shape	Available
TiC-DS015045	≥99.5%	Spherical	15-45 um
TiC-DS015053	≥99.5%	Spherical	15-53 um
TiC-DS045105	≥99.5%	Spherical	45-105 um
TiC-DS045150	≥99.5%	Spherical	45-150 um
Customizable	≥99.5%	Spherical	Sieve as required

Spherical Titanium Carbide Powder (Aggregated)

Spherical TiC granulated powder is made of 100-300 nm submicron ultrafine TiC powder. It has the advantages of fine particle size, good fluidity, low oxygen content and low cost. Spherical titanium carbide powder can greatly reduce the sintering temperature of ceramic products, refine the grains and improve the mechanical properties. In addition, spherical TiC powder is loose and can be depolymerized and dispersed by conventional means, and can be mixed with other powders evenly. It can be used as main phase or additive of cemented carbide, cermet and special ceramics. The details are as follows:
1. Used for coating materials, such as diamond coating and electric contact material coating;
2. It has the advantages of high hardness and good wear resistance;
3. It can be used to prepare foam ceramics, such as titanium carbide splash ink ceramics;
4. It can be used for reinforcing particles of aluminum alloy, titanium alloy and magnesium alloy;
5. TiC film is used in cutting tools, dies, superhard tools and wear and corrosion resistant parts.

Spec	Ti+C	Free C	Impurities ( ≤ %)							Average Particle Size
	%	≤ %	O	N	Fe	Ca	Si	Al	Na	um
TiC-ES035	≥99.5	0.20	1.00	0.02	0.02	0.02	0.02	0.01	0.01	D50 30-40 um
